3D LED Display With its very high contrast and sense of depth, 3D LED can produce very impressive immersive experiences and is often used in high-end showrooms, shopping mall atriums or corporate headquarter lobbies.
An outdoor naked-eye 3D LED display becomes a new card for the digital city building with high brightness, water-proof, seamless matching corner and shocking 3D vision.
It can create a holographic effect of objects levitating without obstructing background light or the viewer's line of sight, resulting in a very "futuristic" digital effect.
Excellent visibility even under direct sunlight
Suitable for outdoor urban environments
Stable performance in different weather conditions
Attracts tourism and business attention
Status Screen There are no glass separates between status screen and instrument dial which can be clearly seen. It is a Injection molding waterproof rubber treatment, fixed screen body by screws IP65 waterproof dustproof rear case of display.Superb workmanship and the systematic check process ensure the quality of product.
3D screens are usually L-shaped or curved. Together with the patent 45° beveling module, a zero-gap transition between two 90° corners can be realized to completely eliminate the visual break.
The outdoor 3D screen brightness can reach 6000-8000 nits, which make the 3D effect still vivid and realistic under the strong direct sunlight. The screen using COB packaging technology converts the point light source to the surface light source, the light is softened, even if you watch from a short distance no feeling of granularity
| Model | P2.5 | P3 | P4 | P5 | P6 | P8 | P10 |
|---|---|---|---|---|---|---|---|
| Usage | Outdoor | ||||||
| Cabinet Size(mm) | 960*960 | ||||||
| Cabinet Resolution (dot) | 384*384 | 320*320 | 240*240 | 192*192 | 160*160 | 120*120 | 96*96 |
| Scanning | 1/16S | 1/16S | 1/10S | 1/8S | 1/8S | 1/5S | 1/2S |
| Packaging Technology | SMD | ||||||
| Installation | Front/Back | ||||||
| Density(dot/㎡) | 160000 | 111111 | 62500 | 40000 | 27777 | 15625 | 10000 |
| Brightness(cd/㎡) | 5000 | 5000 | 5000-6500 | 5000-6000 | 5000-6000 | 5000 | 4000-7000 |
| Max. Power Consumption(W) | 1000 | 1000 | 900 | 800 | 800 | 800 | 1000 |
| Average Power Consumption(W) | 350 | 350 | 300 | 400 | 300 | 300 | 500 |
| Cabinet Weight (kg) | 40 | ||||||
| Cabinet Material | Iron | ||||||
| IP Rate | IP65 | ||||||
| Grayscale | 10000:1 | ||||||
| Refresh Rate(hz) | 3840 | ||||||
| Frame Change Frequency | 50/60Hz | ||||||
| Horizontal Viewing Angle | ＞140° | ||||||
| Vertical Viewing Angle | ＞140° | ||||||
| Best Viewing Distance | >2.5m | >3m | >4m | >5m | >6m | >8m | >10m |
| Input Voltage | AC110-220V | ||||||
The naked eye 3D large screen is made with P3/P4 high resolution distance and IP65 protection. The unique corner seamless technology combined with customized 3D material, realizes product effect and brand effect in one.
3D LED displays are used for the digital restoration of cultural relics, the immersive reproduction of historical scenes, and digital wayfinding.
The 3D LED display system of the holographic cinema supports 8K ultra high definition resolution, enabling the audiences to enjoy a futuristic, 3D without glasses immersive viewing experience.
3D digital display terminals, designed specifically for exhibitions, can showcase product details and are a high-end choice to enhance the technological feel of a booth and increase visitor numbers.
For applications with limited installation space, personalized brand displays, visually striking stage effects, and crowd-attracting commercial spaces, 3D LED displays are the best choice.
Conventional displays are limited by standard module sizes, making them unsuitable for irregular installations, limited spaces, and irregular structures. They lack visual impact and fail to convey the brand's intended message. 3D LED displays break these limitations. The shape and size of the display can be customized based on design drawings and spatial structure. Even irregularly shaped displays can become part of the brand's visual identity.
We offer options for both indoor and outdoor use. We provide various specifications including P2, P3, P4, and P5. Designs can be tailored to installation distance, viewing angle, and brightness. Display shapes can be customized to customer requirements. Besides standard rectangles, we can customize circles, arcs, irregular shapes, and any shape including brand logos.
Our factory has the capability to design and customize irregularly shaped screens. We provide structural design and display solutions. Based on the customer's design drawings and initial ideas, we can complete the entire concept from structure to display.
The factory manufactures and designs various types of LED screens, including indoor and outdoor circular LED screens, curved LED screens (inner and outer curves), LED logo screens (designed according to brand concepts), and rotating LED screens.
These products allow brands to quickly attract consumers' attention within limited spaces.
No. Naked-eye 3D technology is used on the display, so you don't need any glasses.
Usually in the range of P4 to P10, which is determined by the distance from which it will be viewed and the size of the project.
Perfect Yes, but corners or curves create a stronger sense of depth.
Yes. Naked-eye 3D screens require specially produced 3D video content.
It depends on pixel pitch and screen size, but most outdoor 3D screens are optimized for mid-range viewing distances.
Shenzhen Topview Display Technology Co., Ltd. is a leading LED display manufacturer in China. If you need an excellent LED display factory, Topview Led Display is your first choice. Please send us your detailed requirements so we can provide you with a quote immediately.
